The TD series single-stage inline circulation pump is equipped with a standard motor and mechanical seal. Compared to similar products, this pump's structure is less affected by impurities in the pumped liquid. The product is designed with a top-pull-out assembly, allowing maintenance of the pump without impacting the pipeline system.
The TD pump is a versatile product that can transport a wide range of media, from potable water to industrial liquids. It is primarily used as equipment for liquid transportation, boosting, and circulation. Examples include regional heating systems (the water quality in the heating system should meet recognized water quality standards for such systems), HVAC systems, cooling systems, domestic hot water systems, industrial liquid transportation, and water supply systems.
This product is suitable for transporting clean, non-flammable, non-explosive, and non-aggressive liquids that do not contain solid particles, fibers, or substances with chemical properties similar to water. If the fluid being transported has a significantly higher viscosity or density, it may lead to a drop in the pump's performance curve and an increase in energy consumption.
Maximum Working Pressure: Standard type: 12 bar; Special type: 16 bar Liquid Temperature: -15°C to 110°C
Ambient Temperature: Up to 40°C
Altitude: Up to 1000 m
Rotation Direction: Clockwise (when viewed
