The pump adopts a vertical structure, with the inlet and outlet diameters being the same and located on the same centerline. It can be installed in pipelines like a valve. Its compact and elegant design requires little space, reducing construction investment. With an additional protective cover, it can be used outdoors.
The impeller is directly mounted on the extended shaft of the motor, resulting in a short axial size and compact structure. The pump and motor bearings are configured reasonably, effectively balancing the radial and axial loads generated during pump operation, ensuring smooth operation, low vibration, and low noise.
The shaft seal uses a mechanical seal or a mechanical seal combination, featuring imported titanium alloy sealing rings, medium-temperature-resistant mechanical seals, and wear-resistant hard alloy materials, significantly extending the service life of the mechanical.
Easy to install and maintain, requiring no disassembly of the pipeline system. By simply removing the coupling seat nuts, all rotor components.
The pump can operate in series or parallel modes according to the flow rate and head requirements.
The pump can be installed vertically or horizontally according to the pipeline arrangement.
